Pedal Powered Generator
https://www.los-gatos.ca.us/pedgen.html
A 36" particle board disk with a groove routed in the edge serves as the flywheel and crankshaft for the permanent magnet 36 volt DC motor ( 1 2 ) seen at the upper right edge of the device. A small-pitch chain provides the power transfer system. The groove around the outer edge is lined with "rim strips" - thin rubber straps that prevented the chain from slipping and digging into the particle board. They are standard bicycle parts. The motor was obtained around 1985 from Northern Hydraulic, now known as Northern Tool and Equipment Company.
The bottom frame is welded steel plate and channel, the crankset is an American Schwinn ball bearing set, a cotterless crank conversion spindle, alloy cranks and cheap pedals with toe clips.
The crankset has a steel chainwheel on it. I drilled some larger holes in the chainwheel and bolted the particle board disk to it. It was strong enough (fine Schwinn steel!) to hold the weight of the particle board disk and run true. I routed an oblong hole through the particleboard disk for the "arm" of the crankset.
The seatpost and handlebar tube are standard galvanized water pipe. The generator/motor is mounted on a piece of 3/4 plywood visible in the motor pictures seen above, which is then bolted to the water-pipe frame.
The particle board disk is a key feature of this unit. The weight of the disk serves as an excellent flywheel. Human legs and pedals create an extremely "peaky" torque curve, resulting in jerky motion and lots of stress on parts. The flywheel smoothes this all out by absorbing part of the energy on the power stroke, lowering peak torque, and releasing it on the "dead" part of the stroke, creating torque where human legs/pedals cannot generate any. Another thing to remember is that human legs do not like extreme stress. The flywheel allows the human to avoid having to generate extreme pressure during the power stroke just to make it past the "dead" spots. Many "bicycle converters" lack the flywheel characteristic because tires/rims are designed to be so light.
Noisy but extremely efficient, I have powered 12V CHAIN SAWS directly (yes, while someone else cut wood with them) with this unit.(1) Pedaling position was similar to a bicycle. The seat is barely visible at the upper left of the photo, and the handlebars (dropped, as on a ten speed road bike) are at the upper right.
Burst output: 25 amps at 17 volts (425 Watts)
30 minute average output (back when I was in shape) 150 Watts
Accessories:
A drill chuck threaded into the end of the motor shaft provided power for a flexible shaft drive. Drilling 1/2" holes through 2x4 fir with this arrangement was easy. The flex-shaft was rated at 1/2 HP (a commercial unit, about 3/4 in. thick - not a "dremel" type!!) and I was still worried that the torque would be too much for it.
For immediate electrical use, cigarette lighter outlets provided ready access to the juice. I even had a small 12v toaster oven, and pedaled my bagels to toast more than once. For storage I would charge a 12v 100Ah fork-lift battery. I could approximate the output of a 10 amp battery charger.
Be careful - I burned out several expensive 12v halogen bulbs powering them directly. I had no voltage control and exuberant pedaling would fry the bulbs in short order. When the storage battery was connected, this was less of a problem because the battery tended to even out the voltage, but sprinting would still raise the voltage to the danger level.
At one point a ball-bearing 3600 GPH pump was substituted for the generator, resulting in amazing water pumping capacity. The suction from the pump was strong enough to collapse the heavy wall 1 inch vinyl tubing used for the intake (radiator hose would have been better, with the wire reinforcement) and the output shot a stream of water about 25 feet across the street. A 5 gallon bucket was emptied using this pump in less than half the time it took a garden hose to fill it. I believe the pump was driven to capacity (1 gallon per seconds, emptying the bucket in five seconds) in sprints.
Instrumentation consisted of a voltmeter and an ammeter, which together provided me with state of battery charge, output watts and somewhat of a "speedometer." The math was easy: VOLTS x AMPS = WATTS. A 50 amp silicon stud diode mounted to a four inch square piece of aluminum sheet metal prevented reverse current flows, and became satisfyingly warm after long sprints (it is mounted in the center of the aluminum plate visible in the first motor picture). For top efficiency (and safety), a switch was also installed to completely isolate the diode and motor/generator from the battery.
I never had a chance to determine how efficient the unit was in converting mechanical energy to electrical energy, but I believe it was probably quite good. When running, only 4 ball bearings were turning, the only high-speed part was the armature of the motor, and I know from research that chains can be as high as 97% efficient in power transfer. The permag motor was probably better then average at power generation, because it was designed to be efficient as a motor. In "reverse" tests, with the motor driving the unit with no load, the power consumed was less than an amp at 12 volts. This is negligible, and much of it was resistance loss in the motor windings, since the motor drew half an amp with no load connected to it.
Status: The device out-lasted me. I still have the motor and flex-shaft, but several job-related moves finally forced me to dismantle the unit.
Future: There are many other possibilities that I can think of for this device. The efficiency and variable speed of the output are two features that can be exploited. Here are some other devices that could be powered by the basic unit:
- Pedal powered backup generator for solar electric systems. With the newly available white LED as a light source, a few minutes of pedaling would be enough to create hours of light.
- Pedal powered washing machine (this would be a tremendous workout, especially with the spin/sprint at the end!)
- Pedal powered clothes dryer (when combined with a simple solar hot-air collector, the pedals would tumble the clothes and move the air)
- Pedal powered whole-house ventilation fan (15 minutes in the evening to cool off an entire house)
- Pedal powered watering system when combined with a cistern to store rainwater
- Pedal powered whole-house (central) vacuum cleaner - requires two people, of course
- Pedal powered air compressor (compressing air takes a LOT of power, and is not very efficient. This would work for small jobs only, like staple guns, caulking guns, small hand tools - no jackhammers!!)
- Pedal powered offset printing press, sewing machine (an ancient idea), hand tools (grinder, buffer, drill, reciprocating saw, lathe), mulch grinder
Basically, any device that was hand cranked, foot-powered, or powered by a fractional horsepower electric motor could potentially be converted to pedal power.
Also note, if the base unit is being used to power an auxiliary device instead of producing electricity, adding a solar panel will result in additional power from the motor! That means whatever device you are powering would receive the combined power of the human pedaler and the solar panel. This combination makes the best of both power sources, as efficiency would be very high, because the solar output would not suffer the losses of being stored and then extracted from a battery. Charging a battery and then extracting the same power is less than 80% efficient, and can be much worse. Direct utilization captures that wasted power.
Finally, keep in mind that a tandem setup for the pedals, with the pedals out-of-phase, doubles the power and smoothes out the power flow. Only one "flywheel" is needed, so this enhancement needs only a simple pedal/seat addition to the basic unit. With out-of-phase pedals, peak torque is not increased, so other parts of the system are not stressed. The torque curve for a complete revolution of the flywheel simply smoothes out, while RPM's stay constant, resulting in twice the power.
Over time, a number of questions have asked about the information on the page. Here are some Frequently Asked Questions and answers/opinions:
Do you have plans available?
No. I am working on drawings of this generator and a recumbent version, but they are not yet available.
Would a car alternator work better for generating power?
No. Most automotive alternators have one ball/one sleeve bearing, a built-in power-robbing cooling fan, and they require external power to excite them at low-to moderate RPM's. They have never been designed with efficiency in mind, since they were attached to monstrous motors capable of producing orders of magnitude more power than the alternator required. They actually produce AC power, which subsequently must be rectified to DC to charge batteries. This step causes significant power loss in the diodes (around 5%). As I noted above, I ran power output around the diode and directly into the battery to avoid this loss. In addition, alternators are designed to run at extremely high RPM's (alternator pulleys are smaller than the driving pulley on the engine, meaning the alternator turns FASTER than the car engine. Look at your tachometer reading and double it. Whew!), and do not produce usable power until they are rotating quite rapidly, requiring high ratio's of step-up from your pedals. A well-designed permanent-magnet ball-bearing motor, preferable one designed to squeeze every last bit of power out of a set of batteries, will beat an automotive alternator in efficiency.
Wouldn't gears help generate more power? And what about belts instead of chains?
Maybe. Humans can only pedal through a small speed range, about 40-120 RPM's. Below that you can strain your joints, and above that efficiency falls off. There is a "magic" speed (different for every human being) at which they can generate maximum power. The proper gear ratio enables the human to pedal at that speed. You may have noticed, though, that a human's maximum power output can change quickly from fatigue, and slowly from changes in conditioning and age. The magic speed is always changing, so having a few closely-spaced "gears" or ratios may enable a better match of human to generator. No matter what, though, gears don't create energy, they waste energy, so having fewer of them is always better. The same goes for bearings, even ball bearings. The pedal-power generator described on this page had very few of both, so it was very efficient.
Regarding belts, the transfer efficiency of most belts is less than chains. This is mostly due to flexing energy loss within the belt material and friction losses at the engagement points between the belt and the pulleys. Belts also work best when transferring low torque at high speed (the opposite of what a pair of legs produce!) which is why you do not see them on bicycles, for example. There may be some exotic, thin, high strength belts that could approach the efficiency of chains with the right design. For example, the "serpentine" belts used in modern automobile engines are much more efficient than the old "V-belts" from the past. Belts rely on friction to transfer power. Friction is bad. The best feature of belts is that they are quiet, so I can't say to avoid them completely. If you decide to use a belt to transfer power, use the thinnest, strongest belt you can find, and place only enough tension on it to keep it from slipping during use. I do not know whether equivalent "toothed" and "grooved" belts are equally efficient, but I believe the toothed belt has slightly lower friction losses. If I can ever find some real research data on the web I will link it in here.
How much power can one human being create?
This is an opinion. I used to be a competitive swimmer, and for a number of years, I worked out 6 hours a day, swimming approximately 13 miles. Yes, 13 miles a day. If you pedaled that hard for that long you might be able to run one ordinary refrigerator for 24 hours. To make any kind of significant contribution to your energy supply, you must use the most efficient devices you possibly can. For example, a small refrigerator designed to be powered by solar power would be much more practical. A rule of thumb: if the device was designed to be powered by batteries, even BIG batteries, you might be able to keep up with it.
If your electric bill shows KWH (kilowatt-hours), take the number, multiply by 4 (assuming you can crank out 250 watts for an hour) and that is how many hours you will have to be in the saddle to create the same amount of power. Sorry, it can be depressing. The moral: Using less power is as important, if not more important, than making more.
There are numerous sources of efficient appliances on the web. One place I like to shop is Real Goods, and of course I have spent time inventing my own efficient devices. The white LED light I built shows how technology can create new solutions to increase efficiency. Pedaling for an hour at the 200 watt pace, with 80% efficiency of generation/storage/extraction, would create enough energy to run that light for 320 hours!!!
Can I generate 110V? Can I run my electric meter backwards?
I don't recommend this! If someone were to replace the permanent magnet DC motor in a pedal generator (such as the one on this page) with a 1/4 to 1/2 horsepower 110V induction motor and pedal that it would result in an amazing thing. If the motor was hooked to the power lines and it was "pedaled faster than it wanted to go", it would start generating 110V alternating current. Beautiful sine wave AC. If it was creating more energy than your clocks, refrigerator, all those little square black power supplies you have plugged in around the house, your lights, and that 300 watt stereo you are listening to while you pedal all use together, your electric meter would slowly creep backwards. However, that same motor would generate exactly 0 power if it is not plugged in to 110V AC.
For very light duty "off the grid" use of 110V AC, you can try pedaling your 12V DC generator into a large battery and hooking up an inverter (12V DC - 110V AC) to get some pretty decent 110V power. You CAN'T use this method to "run your meter backwards"!!!! In general, plan on being able to pedal about 100-250 watts for half an hour or so.
For efficiency, however, you are much better off producing 12V DC for a 12V DC TV (for example) than you are producing 12V DC to charge a battery to run an inverter to power a 110V AC TV. The UPS (uninterruptable power supply) for my website computer system can power the computer for about five minutes. The same battery (12v 1.5 AH) would power my laptop computer for about 45 minutes. Everything (efficiency-wise) works FOR you when the device being powered is designed to be efficient (12V DC) and AGAINST you when it is not (110V AC).
How big should my batteries be?
If you are considering building a similar system, plan on using two batteries, and a simple switch which allows you to use one while charging the other. Flip this switch right before you begin charging to ensure that you are charging the battery with the lowest charge (the one most recently used). Also be sure to use a battery that is roughly equal to ten or twenty times your power output for a charging session. For example, if you crank out ten amps for an hour each time you charge, choose a 100-200 amp hour battery. Larger batteries will simply loose charge through self-discharge faster, resulting is less efficiency for your system and more useless work for you.
Remember:
1. The most efficient way to use the power you create is not to create electricity at all, but to power your (pump, fan, hoist, winch, drill press, grinder, sewing machine, etc.) directly.
2. The second most efficient way to use the power is to pedal a generator to electrically power your (television, radio, floodlight, chain saw, laptop computer) directly, with no battery. Be careful about voltage, or use a good regulator.
3. The least efficient way to use your power is to generate electricity and store it in a battery, then extract it from the battery to power some device. Avoid this method in favor of methods 1 and 2!!
For more information, read this excellent writeup giving details on a different design based on a bicycle and rollers. .
